NASA Is Learning The Best Way To Grow Food In Space
The Voorhes
NASA Is Learning The Best Way To Grow Food In Space
Can gardens help astronauts go farther?
By Sarah Scoles June 6, 2018
“Our plants aren’t looking too good,” astronaut Scott Kelly tweeted from the International Space Station on December 27, 2015. He was right: The attached picture showed four baby zinnias bathed in magenta light. Three of the four leafy stalks were discolored and curling in on themselves. The station’s garden was struggling to recover from a mold problem. It’s an issue familiar to terrestrial gardeners. And while on Earth, the problem means a trip to the local nursery for replacements, in space you can’t do that.
Space gardens will be essential someday if astronauts are to go beyond low-earth orbit or make more than a quick trip to the moon. They can't carry all the food they need.
The Voorhes
The zinnias, brightly colored flowers in the daisy family, were part of an experiment called Veggie, whose ultimate mission is to provide crews with a long-term source of food. In prior tests, astronauts had successfully harvested lettuce. The zinnias had a longer growth period—60 to 80 days—and then would bloom, producing neon-hued blossoms that look like they belong in a psychedelic corsage. They were practice for something finickier and tastier than leafy greens: tomatoes. If station crews were ever going to grow something that intricate, they needed to figure out—among other things— how to vanquish mold.
Veggie is a relatively uncomplicated way for astronauts to develop their green thumbs. “It’s a very simple system,” says Gioia Massa, one of the project’s lead scientists. “It doesn’t control much at all.” Instead, the humans do.
Space gardening will be essential someday if space travelers are to go beyond low-Earth orbit or make more than a quick trip to the moon. They can’t carry on all the food they need, and the rations they do bring will lose nutrients. So astronauts will need a replenishable stash, with extra vitamins. They’ll also require ways to make more oxygen, recycle waste, and help them not miss home so much. Space gardens can, theoretically, help accomplish all of that.
Veggie and other systems aboard the space station are helping researchers figure out how radiation and lack of gravity affect plants, how much water is Goldilocks-good, and how to deal with deplorables like mold. Just as important, scientists are learning how much work astronauts have to put in, how much work they want to put in, and how plants nourish their brains as well as their bodies.
For all its potential importance, Veggie is pretty compact. It weighs 41 pounds, just a hair less than the station’s 44-pound coffeemaker. The top—an off-white rectangular box that houses the grow lights—resembles an old VCR. From this, a curtain of clear plastic hangs to encase the 1.7-square-foot planting surface. Astronauts preset how long the lights stay on each day; how brightly they emit red light to optimize photosynthesis, and blue light to control the plants’ form and function. They can also activate a built-in fan to adjust the humidity.
The most important part of Veggie, though, is the fragile bounty it is meant to cultivate. That begins as seeds encased in little Teflon- coated Kevlar pouches. The scientists call them plant pillows. “You can think of it like a grow bag,” Massa says of these packets stuffed with seeds, water wicks, fertilizer, and soil.
People have anticipated this scenario for more than a century. In 1880, science-fiction author Percy Greg wrote Across the Zodiac, a novel about an astronaut who traveled to Mars with plants to recycle waste. Fifteen years later, Konstantin Tsiolkovsky, a Russian rocket scientist, wrote Dreams of Earth and Sky, which laid out how spacefarers and flora could live together inside a closed system.
In the 1950s, green things burst from book covers and into the lab. NASA and the U.S. Air Force started growing algae to see if it could help with life support (turns out, it tasted bad, was full of indigestible cell walls, and had too much protein). Then, Soviet scientists experimented with nearly self-sufficient ecosystems in which humans survived on oxygen, water, and nutrition produced mostly within an enclosed habitat. In the longest run, a 180-day trial inside a facility called BIOS-3, an earthbound crew got 80 percent of its food from its own wheat and vegetables. Finally, in 1982, plants in space became a reality when Soviet cosmonauts grew Arabidopsis thaliana, a flowering species related to cabbage and mustard, to maturity aboard their Salyut 7 space station. The yield was too small to be a source of food.
LIQUID REFRESHMENT
Astronauts dispense precise amounts of water to the plants inside Veggie.
NASA
Around this time, in the mid-’80s, Veggie’s Massa was in middle school, and her seventh- grade teacher returned from an astroagriculture workshop at Kennedy Space Center with reams of information on the topic. Inspired, a teenage Massa kept taking ag classes as she moved on to high school and later teamed up with her middle-school mentor for a hydroponics project.
While Massa continued her studies and self-guided experimentation, NASA began building orbital plant-growing apparatus, most notably the Biomass Production System. Designed to be used for experiments on the space station, it was a rectangle with sides each about the length of an arm. Four cube-shaped growth chambers rested like safes inside. Designed by scientists at a Wisconsin-based company, Orbitec, the Biomass Production System joined the space station in 2001. There, Brassica rapa field mustard soon sprouted tall, illuminated by plain white fluorescent light.
When researchers compared the harvest to a control plant on the ground, though, they found that the space mustard had more bacteria and fungus. “The significance of the difference is uncertain,” states NASA’s official conclusion. By which the agency meant it didn’t know why the microbes proliferated, not that their presence wasn’t important. In fact, as Veggie’s mold would show, it was critically important.
NASA retired the Biomass Production System in 2002, but Russian cosmonauts picked up where the U.S. left off. Over the decade, they successfully grew dwarf wheat, leafy mizuna, and dwarf peas. Bonus: In four successive generations of orbiting dwarf peas, the vegetables didn’t show signs of genetic messiness.
Could underwater farming feed the world?
Ocean-bound entrepreneur envisions ecological restoration and economic revival.
American entrepreneur Bren Smith says he can feed the world with an area roughly the size of Washington State. And he wouldn’t need one inch of farmland to do it.
Meanwhile Orbitec, in consultation with NASA, cultivated another plant-growing instrument. So when NASA awarded a grant in 2012 for a new space garden, the company had something to show for itself: Veggie, which, unlike its predecessor, was meant to produce food on an edible scale. Massa, by then a postdoc, tested different types of media and crops for the plant pillows. It was the kind of tinkering she’d been preparing for since she was 12. The United States’ first real space garden launched in 2014, not long after Massa advanced from her postdoc to become a Veggie project scientist at the space agency.
All went pretty well for Veggie until the flower flap. Most of its initial edible plants—a lettuce variety called Outredgeous—sprouted as they should have in 2014, and the astronauts shot them back down to Earth for testing. Massa says they’re still working on all the analyses. “But in general, the plants are pretty similar to our ground samples.” When they’re finished, they’ll know about chemical contents like antioxidants, anthocyanin (pigments), and phenolics, which protect plants against stress. Short term, the priority was mealtime: Could we have consumed the harvest? The crew, Massa, and NASA all wanted to know. Yes, it turned out, the produce was microbially safe to eat.
Kevlar-coated pouches help protect seeds from microbial contamination; fully grown Outredgeous lettuce NASA
Still, when the astronauts planted a second set of seeds, in summer 2015, Massa ran into a new challenge: With harvest approaching, NASA had no protocol to approve the crew chowing down on the leaves of their labor. “We said, ‘We have only 28 days, and then they’re going to have to eat it,’” Massa recalls. With the clock ticking, management found a way to officially add the lettuce to the astronauts’ diet.
On August 9, Kelly snapped a picture, standing in front of the unfurling greens. His brow was furrowed, faux-serious. “Tomorrow we’ll eat the anticipated veggie harvest on @space_station!” he tweeted. “But first, lettuce take a #selfie.” Soon he crunched the harvest live on NASA TV. It might seem like no big deal, but a single leaf can make a big difference to someone who’s been eating rehydrated fare for months. During a later harvest, astronaut Peggy Whitson would use them to wrap a reconstituted lobster salad. “Even with a really good diet with hundreds of items, there’s dietary fatigue,” Massa says. “People get bored. Adding a new flavor or texture—like something crisp and juicy—could spice up your regular meal.”
That’s not the only brain boost. Sure, astronauts can gaze down at Earth and see its most beautiful spots—literally all of them—every 90 minutes. But those places are always out of reach, reminders of how far away sea level is. Having something nearby that photosynthesizes might cheer the crew. “It’s the psychological aspect of something green and growing when you’re far away from home,” Massa says.
In the next growing cycle, the astronauts fostered the ill-fated zinnias. About two weeks in, Kjell Lindgren saw the first warning signs. Water leaked from the wicks that hold the seeds. Then moisture began seeping from the infant leaves, which started to curl in on themselves. Veggie staff on the ground, in charge of the operation, decided it was time to turn the airflow fan from low to high. But an impromptu spacewalk to fix a broken robotic arm delayed the change because, in space, nothing is as simple as flicking a switch on your way out of the spaceship. While reprogramming Veggie’s settings takes only about 15 minutes, NASA prefers astronauts move anything lower priority out of the way when they have a high-priority task.
And then the leaves started to die.
That’s bad enough on its own. But, worse, dying vegetation can be a breeding ground for mold, which had somehow come to space with the astronauts and cargo. Soon, menacing white fuzz began choking the plants.
By this time, Lindgren had returned to Earth, and Kelly had taken over the garden. On December 22, with instructions from ground control, Kelly snipped away the moldy parts like bad spots from a piece of cheese, and swabbed the remaining zinnias and equipment with cleaning wipes. He left the fans on high to help dehydrate the setup.
It was a good try but not without a cost: It made the plants thirsty. Kelly relayed that to ground control and asked to water them. Sergeants who were set on sticking to the drill told Kelly it wasn’t time yet. Not till December 27. “You know, I think if we’re going to Mars, and we were growing stuff, we would be responsible for deciding when the stuff needed water,” Kelly told them, according to NASA’s write-up of the event.
FARM TO TABLE
On-Orbit Gardeners Kjell Lindgren (left) and Scott Kelly. The fast-growing salad green was the first plant to be grown, harvested, and eaten in space. NASA
Eventually, they gave autonomy to the person who was actually next to the plants, along with one page of instructions called “The Zinnia Care Guide for the On-Orbit Gardener.”
Under the On-Orbit Gardener’s thumb, half of the zinnias revived, unfurling and growing green. NASA spun the whole thing as a positive: They now knew that crops could survive floods, drought, and disease and that excising the problem plants and cleaning the remainder could keep the fungus from taking over.
Kelly loved the now-flourishing flowers and carried their container all over the space station for photo shoots, like those people who snapshots of themselves in Hard Rock T-shirts all over the world. “He asked if he could harvest them on Valentine’s Day,” Massa says. He’d been in space, away from everyone except his smelly crewmates for more than 300 days. NASA let him make the bouquet.
It was one of Massa’s favorite moments. “We had been a part of something that gave him pleasure,” she says.
In upcoming Veggie experiments, scientists will learn more about that part of gardening—the mental part. “We’ve heard a lot anecdotally,” Massa says, “but we’ve never been able to collect data.” They’ll also investigate how much farming crewmembers actually want to do, how much is fun versus how much is a chore, how their sense of taste changes in orbit, and which plants can survive human error (no offense, astronauts).
Veggie’s experiments will continue in tandem with those of a brand-new Type-A companion, the Advanced Plant Habitat, an 18-inch-square self-sufficient laboratory with more than 180 sensors and automated watering. Scientists can establish their variables and thus nail down the specific conditions that cultivate plants—and how those plants can cultivate humans. A temperature-control system keeps the air within 0.5°C of the thermostat setting. Sensors relay data about air temperature, light, moisture, and oxygen levels back to base. While the Advanced Plant Habitat will quantify the circumstances for successful gardening, Veggie will help qualify how—and why—humans can facilitate their own food supply. In other words, through the habitat’s tight controls, researchers can learn how to grow which plants best. Then, using those parameters, they can set up a system like Veggie that astronauts get to interact with.
Astronauts assembled the habitat over six hours in October 2017, after it rumbled into space in two shipments. The automated contraption looks like a microwave that could survive… being shot into space. Wires stream from here to there and there to here on a control panel. Red indicator lights blink next to toggle switches. And inside the plant chamber, LEDs beam from the ceiling, illuminating the plants below with concert-stage color combinations. It has red, green, and blue lights like Veggie—plus white, near-, and far-infrared ones.
Plants might also be a brain boost. "It's the psychological aspect of having something green and growing when you're far away from home," says Massa.
The Voorhes
Robert Richter, director of environmental systems at Sierra Nevada, which acquired Orbitec in 2014, monitored its progress from the earthbound Space Station Processing Facility. He’d helped design and build the new lab, as well as Veggie and Biomass. When he started in the field, almost 20 years ago, he was a bit naive. “I thought, How hard is it to grow plants?”
He’s partly joking, of course—and he knows, now, that when you’re trying to keep the humidity level within 3 percent of a given number, when you must make and measure light and moisture, and when you maintain the temperature to a fraction of a degree, there’s a long row to hoe between growing some basil in a cup and farming lettuce in space.
The team powered up the unit in November 2017. And by February this year, test crops of Arabidopsis thaliana and dwarf wheat sprouted. Soon, they’ll begin experiments like investigating plants’ DNA and physiological changes. A lot of the previous plant research has been focused on whether things would grow at all, says Robert Morrow, Sierra Nevada’s principal scientist. Will they reproduce from generation to generation? And are they as productive in space as on the ground?
Yes, he says. Scientists are beyond those basics now. They need to dig into the dirtier details and more-complicated ecosystems. Astronauts, for instance, exhale carbon dioxide that plants can inhale. The plants then exhale oxygen, which humans can inhale. Human waste can become plant fertilizer and hydration. Nothing wasted, everything gained.
Ultimately, Morrow believes, a garden on a deep-space mission will be more like Veggie than like the Advanced Space Habitat. “It’s really not practical to put all the stuff you have in APH in a system like that,” he says. With so many sensors and tubes, lots can go mechanically wrong, and it’s easier to repair a Veggie than an APH. For now, scientists need APH to home in on optimal guidelines for plant growth and understand how leaving the planet changes them so they can instruct future astronauts how to better manage Veggie-esque systems.
Looking toward the future, Massa is interested in observing astronaut interactions with the instruments. “Do you always want to pick your ripe tomatoes, but maybe you don’t want to have to water them every other day?” she wonders. She’ll have a chance to find out because Veggie will grow its first dwarf tomatoes, a variety called Red Robin, early next year.
Other nations continue to experiment too. China, for instance, intends to send silkworms and potato seeds to the moon this year aboard its Chang’e-4 spacecraft. When the silkworms hatch, they’ll create carbon dioxide, which the potato plants will suck up and turn into oxygen, which the silkworms will then take up.
All this research doesn’t just help people above the atmosphere. Creating self-contained growth systems might help farmers on Earth grow crops year-round or foster plants with extra protein and high yield. Someday, the work will lead to gardening systems substantial—and stable—enough to support space journeyers. Then, those travelers can wrap anything they want in lettuce and crunch their way through the cosmos.
Contributing editor Sarah Scoles is the author of Making Contact: Jill Tartar and the Search for Extraterrestrial Intelligence.
This article was originally published in the Summer 2018 Life/Death issue of Popular Science.
tags: science gardening farming space travel features summer 2018
Keeping A Close Eye On Ice Loss
Sea Level Rise
Keeping A Close Eye On Ice Loss
AWI contributes two million euros towards the cost of a new satellite mission
[17. May 2018]
A few months ago, the GRACE mission’s two Earth observation satellites burnt up in the atmosphere. Although this loss was planned, for the experts at the Alfred Wegener Institute it left a considerable gap in monitoring ice loss in the Antarctic and Greenland. Now the follow-up mission will finally be launched, and will play a vital role in predicting future sea level rise.
Without a doubt, one of the greatest threats in connection with climate change is the continuing rise in sea level– and the more intensively the enormous ice sheets in Greenland and the Antarctic melt, the worse it will become. To more accurately gauge the loss in mass of these large ice sheets, scientists at the Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research (AWI) permanently evaluate Earth observation data gleaned from satellites. For them, the GRACE satellites were an extremely important pair of spacecraft.
They had been in orbit since 2002, but in 2017, at the ripe old age of 15 they were decommissioned, and early this year they made a controlled re-entry into the Earth’s atmosphere, where they burnt up as planned. Ever since then, the AWI experts and the international research community have had to do without an important source of information on the condition of the large ice sheets.
And now, to fill that gap, at 12:47 p.m. PST on 22 May 2018 the successor, GRACE Follow-On (GRACE-FO) will be launched into orbit from Vandenberg Air Force Base in California (USA). “We’re delighted,” says AWI geophysicist Ingo Sasgen.“For 15 years, the GRACE mission provided us with unique and fascinating time sequences on the ice sheets’ mass losses. Since June 2017, this time sequence has been interrupted, which means that we don’t have any data on the last melt season in Greenland. It’s very good news that the measurements are now going to be continued.”
GRACE stands for “Gravity Recovery And Climate Experiment”. As the name suggests, the satellites' task is to measure the Earth’s gravitational field on a monthly basis. This gravity data can then be used by various experts for different purposes. It is particularly important for the AWI’s researchers because the changes in ice mass in Greenland and the Antarctic can be clearly seen in the Earth’s gravitational field. If more ice is lost as a result of melting or calving than can be recovered through snowfall, the mass of the ice sheet decreases, and so does the gravitational field in that area. Accordingly, the GRACE measurements can tell us whether or not, where, and by how much the ice sheets shrink or grow.
The two GRACE satellites employ a microwave radar system to permanently measure the distance between them and normally fly approximately 220 kilometers apart. If the first satellite flies over an area with higher gravity, it is slightly attracted and thereby accelerated. This increases its distance from the second satellite, and the discrepancy shows how great the change in gravity is within a radius of circa 400 km. The accuracy of this approach is extraordinary – it can measure the distance between the twin satellites to within a few micrometers.
The new GRACE mission will also rely on microwave radar. “To allow the second mission to launch quickly and not to lose too much time and risk gaps in the data, the choice was made to use tried and trusted technologies,” explains Ingo Sasgen. “However, there is also a laser measuring device on board, which will be tested during the mission. Roughly 25 times more accurate than the microwave radar, we believe it can further improve the gravitational field analysis.”
As with the previous mission, the German Research Centre for Geosciences (GFZ) and NASA are providing the scientific support for the GRACE-FO mission. The German Aerospace Center will carry out the mission on behalf of the GFZ. In turn, the AWI will contribute not only its ice expertise but also two million euros to help cover the cost of the Falcon 9 booster rocket from SpaceX.
The data provided by GRACE-FO will be essential, as it will not only allow Ingo Sasgen and his colleagues to help determine how major ice sheets are responding to the on-going global warming; they will also feed the data into mathematical models known as numerical climate models to predict how ice losses will evolve over time. Further, GRACE-FO will conduct high-precision gravity-field measurements, which experts at the AWI will combine with readings from other satellites, e.g. CryoSat-2, which uses radar to accurately measure the thickness of the sea-ice cover. CryoSat-2can be used e.g. to identify which parts of an ice sheet had the most snowfall. In addition, GRACE-FO will scan 400-kilometer grid sections, which is comparatively coarse. Measuring five-kilometer sections on average, CryoSat-2 offers significantly higher resolution. But CryoSat-2 has limitations of its own: its radar sweep also penetrates into the upper layers of snow and ice, making it difficult to precisely measure their thickness, especially since the exact conditions on-site are unknown.
To compensate for this aspect, the AWI also takes calibration readings with its research aircraft. A further source of uncertainty: over time, snow collapses under its own weight, which can skew measurements of its thickness. According to Ingo Sasgen, “With the CryoSat-2 data alone, it’s impossible to say whether a change in the thickness of ice and snow was produced by the snow compacting, or by melting. That’s why we need GRACE Follow-On; the respective change in the gravitational field shows us whether or not ice and snow are actually being lost.” In essence, the satellites constitute a perfect match, as they offer complementary strengths.
With the start of the GRACE-FO mission, after roughly a year an important gap in satellite monitoring will become a thing of the past. As with its predecessor, the planned mission duration is five years. But Ingo Sasgen hopes that the second generation, just like the first, might continue to provide data for as long as 15 years. “We would then have a time series covering roughly 30 years, which would mean a truly representative timespan for climate models. The data gained will be a valuable resource for climate research, today and for decades to come.”
Video: NASA
The Challenge of Space Gardening: One Giant 'Leaf' For Mankind
The Challenge of Space Gardening: One Giant 'Leaf' For Mankind
Kerry SHERIDAN
AFP News 10 May 2018
Tomatoes grow in a LED-lighted box, similar to what astronauts use to grow lettuce on the International Space Station, at Fairchild Tropical Botanic Garden in Miami on April 25, 2018
It's not easy having a green thumb in space.
Without gravity, seeds can float away. Water doesn't pour, but globs up and may drown the roots. And artificial lights and fans must be rigged just right to replicate the sun and wind.
But NASA has decided that gardening in space will be crucial for the next generation of explorers, who need to feed themselves on missions to the Moon or Mars that may last months or years.
Necessary nutrients, like vitamins C and K, break down over time in freeze-dried foods. Without them, astronauts are increasingly vulnerable to infections, poor blood clotting, cancer and heart disease.
So the US space agency has turned to professional botanists and novice gardeners -- high school students, in fact -- to help them practice.
"There are tens of thousands of edible plants on Earth that would presumably be useful, and it becomes a big problem to choose which of those plants are the best for producing food for astronauts," explained Carl Lewis, director of the Fairchild Tropical Botanic Garden, which is leading the effort.
"And that is where we come in."
- Useful foibles -
The Miami-based garden has identified 106 plant varieties that might do well in space, including hardy cabbages and leafy lettuces.
They have enlisted 15,000 student botanists from 150 schools to grow plants in space-like conditions in their own classrooms.
The four-year project is about midway through and is paid for by a $1.24 million grant from NASA.
Using trays rigged with lights that mimic the grow boxes used in space, students must tend to the plants and record data on their progress, which eventually gets shared with NASA.
"We're not using typical gardening equipment," said Rhys Campo, a 17-year-old high school student who tried her hand at growing red romaine lettuce this year.
"We have setups that are a lot more high-tech."
Still, some plants get overwatered, some classrooms are hotter or colder than others, and holiday breaks may leave the grow boxes unattended.
In Campo's class, the lettuce dried up, and students were unable to taste it.
Such foibles have turned out to be an unexpected but useful part of the project, said NASA plant scientist Gioia Massa.
"If you have a plant that does well in all that variability, chances are that plant will do well in space," she told AFP.
- New textures -
Astronauts living at the space station, 250 miles (400 kilometers) above Earth have encountered their share of failures while gardening in orbit, too.
The first portable growing box for space, equipped with LED lights, called Veggie, was tested at the orbiting outpost in 2014.
Some of the lettuce didn't germinate, and some died of drought.
But astronauts kept trying, and finally took their first bite of NASA-approved space-grown lettuce in 2015.
Now, there are two Veggie grow boxes at the ISS, along with a third, called the Advanced Plant Habitat.
The food being grown is only occasionally harvested and amounts to just a leaf or two per astronaut, but it's worth it, said NASA astronaut Ricky Arnold, during a live video downlink with students at Fairchild last month.
"The textures of food are all kind of very similar," he said of the freeze-dried fare available on board the ISS.
"When we are able to harvest our own lettuce here, just having a different texture to enjoy is a really nice diversion from the standard menu."
- The ideal space veggie -
Plants don't need gravity in order to grow. They just orient themselves to the light.
According to Massa, a good space plant has to be compact and produce a lot of edible food.
Plants also have to do well in a spaceship like the ISS, which has a temperature of 71 degrees Fahrenheit (22 Celsius), 40 percent relative humidity, and high carbon dioxide -- some 3,000 parts per million.
"That is something plants aren't adjusted to," said Massa. "On Earth, it is about 400 ppm."
Under a system, Massa described as akin to hydroponics but not exactly the same, space plants also have to germinate from a plant pillow with only a small amount of dirt, do well under LED lights, and be microbially fairly clean, because it is hard to wash vegetables in space.
Some of the student-tested crops are expected to launch in coming months, including dragoon lettuce and extra dwarf pak choi.
By next year, tomatoes could be on the menu
- Connection to Earth -
NASA is looking into the possibility of robotic space gardening, to automate the process so the crew can focus on other tasks.
But many astronauts say they like tending to plants because it helps them maintain a connection to Earth.
"The psychological benefits can be important for astronauts," said NASA research scientist Trent Smith.
Besides -- as many gardeners know -- having a plot dry up or be devoured by mold isn't the end of the world.
"The thing that the students learn is that making mistakes is okay," said JoLynne Woodmansee, a teacher at BIOTech High School in Miami.
"The whole process of science is all about building. You can't learn something new without making a mistake."
